General Technical Specifications |
Scanner Type |
CDF (Continuous Document Feeding), Simplex sheetfeed two-way paper path
(Straight path, U-turn path) |
Scanning Modes |
Color, grayscale, monochrome, automatic (color / grayscale / monochrome detection) |
Image Sensor |
CIS (Contact Image Sensor) x 1 |
Light Source |
3 Color LED (Red / Green / Blue) |
Optical Resolution |
600 dpi |
Scanning Speed (A4 portrait)(1) |
Auto Mode(2) |
5.2 seconds / page |
Normal Mode |
5.2 seconds / page |
Better Mode |
5.2 seconds / page |
Best Mode |
5.2 seconds / page |
Excellent Mode |
20.4 seconds / page |
Document Size(3) |
Normal Mode |
A4, A5, A6, B5, B6, Business Card, Post Card, Letter, Legal and Custom Size.
Max: 216 X 360 mm (8.5 X 14.17 in.), Min: 25.4 x 25.4 mm (1 x 1 in.).
Automatically recognizes document size. |
Normal Mode with Carrier Sheet |
Use of a Carrier Sheet permits the scanning of A3, B4, 279.4 x 431.8 mm (11 x 17 in.) and photographs as well as the document sizes listed above. |
Long Paper Scanning(4) |
Max: 216 x 863 mm (8.5 x 34 in.) (300 dpi or less) |
Paper Weight (thickness) |
52.3 to 209.3 g/㎡, or 14 to 56 lb (Straight path)
52.3 to 80 g/㎡, or 14 to 20 lb (U-turn path)
Card: Portrait or Landscape (Straight path)
Non-embossed 0.76 mm or less
Embossed: 0.76 + 0.48 mm (ISO7810 Conforming) |
Paper Setting |
Front-side up |
Continuous Scanning |
260 sheets (A4, color, simples, 300 dpi, battery operated)(8) |
Interface(5) |
USB 2.0 (USB 1.1 compatible) |
Power Source |
Li-ion Battery (3.7 V / 720 mAh) |
Power Requirement |
5 V / 0.5 A ( x 1port) |
Power Consumption(6) |
During operation: 4.7 W or less
During sleep mode: 2.2 W or less
During Standby (OFF) mode: Less than 0.5 W |
Operation Environment |
Temperature |
5°C to 35°C (41°F to 95°F) |
Relative Humidity |
20 to 80% (non-condensing) |
Dimensions (W x D x H)(7) |
273 x 47.5 x 36mm (10.74 x 1.87 x 1.42 in.) |
Device Weight |
400 g (0.88 lb) |
Environmental Compliance |
ENERGY STAR® compliant/RoHS |
Driver |
ScanSnap specific driver:
• Windows®: Does not support Twain/ISIS®
• Mac OS: Does not support Twain |
