Machine Features:
*One spindle ,one tool magazine + 7 vertical 2 horizontal line boring head (Optional).
*Drum type auto. Tool change system. Tool magazine capacity 8 tools. Tool change time
only 8 seconds. (12 tool is optional)
*Three guide ways, one side driving structure, features heavy duty cutting.
*Vacuum table area can be divided into two vacuum zones. When one zone is machining,
the other zone can be fed material simultaneously. (optional)
*Full sheet of board can be processed directly, not needing prior sawing. This saves making moulds.
*Suitable for machining complex parts of various types and in small quantities.
*Typical applications: cabinet doors, solid wood doors, computer desks and panel type furniture, etc.
|
Table
|
Table size
|
1550x3650mm (5x12ft)
|
|
Max. working stroke
|
X axis
|
3850mm (12.63ft)
|
|
Y axis
|
1850mm (6.07ft)
|
|
Z axis
|
250mm (0.82ft)
|
|
Spindle elevation
|
150mm (5.9")
|
|
Work piece height
|
Max.200mm (7.87")
|
|
Pneumatic boring head lifting
|
150mm (5.9")
|
|
Rapid speed
|
X , Y axis
|
60M/min (196.85ft/min)
|
|
Z axis
|
20M/min (65.62ft/min)
|
|
Spindle
|
Spindle speed
|
1000-24000rpm
|
|
Main power
|
Spindle motor
|
11HP (8kw)x1 HSD
|
|
Vacuum pump
|
20HP (15kw)
|
|
Dimensions
|
L
|
4650mm(15.25ft)
|
|
W
|
2200mm(7.22ft)
|
|
H
|
2300mm(7.55ft)
|
