Thông tin sản phẩm
Ranges: 220, 440, 870, 1750 and 3500 m
720, 1440, 2850, 5740 and 11500 ft
Range Selection: Automatic range control
Resolution: Approximately 1% of range
Accuracy :1% of measurement range *
Velocity: Factor Adjustable from 1% to 99%
Adjustable: from 2,5 to148,5 m/μs
Output Pulse: 5 Vp-p into open circuit
Output Impedance Selectable 50, 75 and 100 Ω
Output Pulse Width 25 ns min. 1.6 μs max.
Scan Rate: 6.7 scans per second
Tone Generator Oscillating: 810 - 1110 Hz
Auto Power Down 3 minutes
Power Supply: 4 x AA cells
Backlit Display: 64 x 128 pixel
Voltage Withstand Protection 250 V AC
Sensitivity: min. 3 pixel return at 2 km(6 kft)
Operating Temperature: 0 °C … +40 °C
Storage Temperature: -20 °C … +70 °C
Safety: IEC61010-1; EN 60950
EMC BS/EN 61326-1
Water: / Dust Proof IP54
Dimensions: 165 x 90 x 37 mm
Weight: 350 g (12 oz)
Option: Fault Converter
Manufacturer: SebaKTM – Germany
