*** FEATURES:
(1) 1/3" HR Color CCD with SONY Effio-E DSP
(2) High resolution
(3) Digital WDR (DWDR) for gradation compensation to improve image contrast
(4) Effective color rolling suppress (CRS) when light fluid fluctuates
(5) OSD menu for advanced settings
(6) Day & night mode support
(7) Built-in microphone
*** SPECIFICATIONS:
|
MODEL
|
AVC412A
|
|
Pick up Element
|
1/3" HR color CCD image sensor with SONY Effio-E DSP
|
|
Number of Pixel
|
771(H) x 492(V) / 753(H) x 582(V)
|
|
Resolution
|
Super high resolution
|
|
S/N Ratio
|
More than 48dB (AGC off)
|
|
Electronic Shutter
|
1/60 (1/50) to 1/100,000 sec.
|
|
Lens Mount
|
CS Mount
|
|
IRIS Mode
|
AES / VD / DD
|
|
Auto White Balance
|
CRS (Color rolling suppress)
|
|
Auto Gain Control
|
ON / OFF
|
|
Digital WDR
|
YES
|
|
OSD Menu for Advanced Settings
|
YES
|
|
Multilingual OSD
|
English / French / German / Spanish / Portuguese / Russian / Japanese
|
|
Video Output
|
1.0 Vp-p composite, 75Ω
|
|
Microphone
|
Built-in
|
|
Power Source (10%)
|
DC12V
|
|
Current Consumption (10%)
|
80mA
|
|
Dimensions (mm)**
|
117(L) x 60(W) x 50(H)
|
|
Weight (g)
|
250g
|
* The specifications are subject to change without notice.
** Dimensional Tolerance: ± 5mm
