Rated frequency(Hz)
|
|
5060
|
Rated voltage(V)
|
|
400/230
|
Rated current(A)
|
|
72.4
|
Rated output power(KVA/kW)
|
|
50/4050/40
|
Maxoutput power(KVA/kW)
|
|
52/4255/44
|
Rated rotation speed(r/min)
|
|
15001800
|
Power factor(cos)
|
|
0.8
|
Phase number
|
|
Three phase
|
Excitation mode
|
|
Brushless self-excitation
|
ATS type
|
|
With(Interface)
|
Electric engine model
|
|
KT-40
|
Structure type
|
|
Open-frame type
|
Fuel tank volume(L)
|
|
100
|
Fuel consumption rate(g/kW.h)
|
|
290
|
Noise level[dB(A)@7m]
|
|
≤84
|
Dry weighe(kg)
|
|
800
|
Overall dimension(L*W*H)(mm)
|
|
1700*800*1200
|
Starting mode
|
|
24V electric start
|
Fuel |
|
0#(summer),-10#(winter),-35#(severe cold)light diesel oil |
Lube |
|
L-ecd grade 15W30 or 15W40 |
Engine model |
|
X4105BZD |
Engine type |
|
Four cylinder,in-line,water-cooled,turbocharged,4-stroke.direct injection |
Bore*stroke(mm) |
|
105*120 |
Displacement(L) |
|
4.156 |
Compression ratio |
|
17 |
Rated power[kW/(r/min)] |
|
49/1500 53/1800 |
Min fuel consumption(g/kW.h) |
|
≤231
|
