Rated frequency(Hz)
|
|
50 60
|
Rated voltage(V)
|
|
230 230/115
|
Rated current(A)
|
|
21.7 23.9/47.8
|
Rated output power(kW)
|
|
55.5
|
Rated rotation speed(rpm)
|
|
3000 3600
|
DC output
|
|
12V 8.3A
|
Power factor(cos)
|
|
1.0
|
Phase number
|
|
Single phase
|
Noise level[dB(A)@7m]
|
|
70~74
|
Overall dimension(L*W*H)[mm(in)]
|
|
910x530x740(35.83x20.87x29.13)
|
Dry weight[kg(ibs.)]
|
|
165(363)
|
Structure type
|
|
Silent type
|
Coupling mode
|
|
Transmission shaft rigid couping
|
Engine model
|
|
KM186FAE
|
Engine type
|
|
Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
|
Displacement[ml(cu.in)]
|
|
418(25.51)
|
Compression ratio
|
|
19:1
|
Rated power[kW(Hp)/rpm]
|
|
5.9(8.02)/3000,6.5(8.84)/3600
|
Starting system
|
|
electric starter
|
Rotation direction(View from flywheel)
|
|
Clockwise
|
Fuel
|
|
0# (summer),-10# (winter) light diesel oil
|
Lube
|
|
SAE10W30(above CC grade)
|
Low oil pressure alert system
|
|
With
|
Excitation mode
|
|
Self-excitation and constant voltage(AVR)
|
