Rated frequency(Hz)
|
|
50 60
|
Rated voltage(V)
|
|
400/230 400/230
|
Rated current(A)
|
|
6.1 7.2
|
Rated output power(kW)
|
|
4.2 5.0
|
Rated rotation speed(rpm)
|
|
3000 3600
|
DC output
|
|
No
|
Power factor(cos)
|
|
0.8(Applied to KVA)
|
Phase number
|
|
Three phase
|
Noise level[dB(A)@7m]
|
|
70~74
|
Overall dimension(L*W*H)[mm(in)]
|
|
910x530x740(35.82x20.87x29.13)
|
Dry weight[kg(ibs.)]
|
|
170(376.2)
|
Structure type
|
|
Silent type
|
Coupling mode
|
|
Transmission shaft rigid coupling
|
Engine model
|
|
KM186FE
|
Engine type
|
|
Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
|
Displacement[ml(cu.in)]
|
|
406(24.78)
|
Compression ratio
|
|
19:1
|
Rated power[kW(Hp)/rpm]
|
|
5.7(7.75)/3000,6.3(8.57)/3600
|
Starting system
|
|
12V electric starter
|
Rotation direction(View from flywheel)
|
|
Clockwise
|
Fuel
|
|
0# (summer),-10# (winter) light diesel oil
|
