Thông tin sản phẩm
Main Function:Rotary tilling
Main Application Range:Dry land,paddy field.
Features:
1)Horizontal output axle,all gear transmission,extra output axle for matching other attachments.
2)Four speed.(Fast,Neutral,Slow,Reverse).
3)Wider tilling area,high efficiency.
4)Matched with a big power diesel engine.
♦Diesel engine
Main Technical Parameter:
| Engine Type |
|
single cylinder,horizontal shaft,4stroke,air cooled |
|
Max Power Output HP(kw)/rpm |
|
10(6.3)/3600 |
| Engine Model |
|
178/186F |
|
Fuel Consumption (L/acre) |
|
2 |
| Transmission |
|
All gear driving |
|
Efficiency(acre /h) |
|
1.5 |
| Gear Shifting |
|
Four speed |
|
Fuel Tank capacity (L) |
|
2.5 |
| Starting |
|
Recoil start |
|
Displacement (cc) |
|
406 |
| Main Function |
|
Rotary tilling |
|
Tilling Depth(mm) |
|
≥100 |
| Net weight (KG) |
|
≤135 |
|
Tilling Width(mm) |
|
1350 |
