Main Function:Tilling,weeding
Main Application Range:Terraced field,Hill sides
Features:
1)Horizontal output axle,all gear transmission,extra output axle for matching other attachments.
2)Small volume,low chassis,compact structure.
3)Fast and slow speed,automatic clutch,easy operate.
♦ Gasoline engine,smooth running,high sensitivity
Main Technical Parameter:
| Engine Type |
|
single cylinder,horizontal shaft,4stroke,air cooled |
|
Max Power Output HP(kw)/rpm |
|
5.5(3.6)/3600 |
| Engine Model |
|
170F |
|
Fuel Consumption (L/acre) |
|
1.1~1.4 |
| Transmission |
|
All gear driving |
|
Efficiency(acre /h) |
|
1~1.2 |
| Gear Shifting |
|
Fast and slow speed |
|
Fuel Tank capacity (L) |
|
2.5 |
| Starting |
|
Recoil start |
|
Displacement (cc) |
|
196 |
| Main Function |
|
Tilling,weeding |
|
Tilling Depth(mm) |
|
100~180 |
| Net weight (KG) |
|
57 |
|
Tilling Width(mm) |
|
870 |
