Main Function:Rotary tilling,weeding
Main Application Range:Orchard,Tea field,Mulberry field,Tabacco field,Green house,etc
Features:
1)A vertical output axle, all gear system.
2)Small volume,light weight,compact structure.
3)Automatic clutch, stepless speed change,user-friendly control.
4)The dust shield is fairshaped design,adopt a material of PP and it’s dismountable, the operator is much more safer.
5)Matched with a hanging tool,the attachments can hang on that.
6)Matched with multiple kinds of attachments to realize a variety of functions.
♦Shineray engine,oil filter,long life time.
♦A simple engine shield.
Main Technical Parameter:
| Engine Type |
|
single cylinder,vertical shaft,4 stroke,air cooled |
|
Max Power Output HP(kw)/rpm |
|
7(4.1)/3600 |
| Engine Model |
|
Shineray engine |
|
Fuel Consumption (L/acre) |
|
1.1~1.4 |
| Transmission |
|
All gear driving |
|
Efficiency(acre /h) |
|
1.1~1.3 |
| Gear Shifting |
|
Stepless speed |
|
Fuel Tank capacity (L) |
|
2.5 |
| Starting |
|
Recoil start |
|
Displacement (cc) |
|
196 |
| Main Function |
|
rotary tilling,weeding |
|
Tilling Depth(mm) |
|
100~180 |
| Net weight (KG) |
|
50 |
|
Tilling Width(mm) |
|
350~870 |
| Package size(mm) |
|
580x480x810(L*W*H) |
|
Overall dimension(mm) |
|
1000*400*740 |
